Softmatter

Thermo Regulation Toolkit

Thermo Regulation Toolkit

Regular price $849.00 USD
Regular price Sale price $849.00 USD
Sale Sold out
Features a collection of our latest heating panels and electronics used in smart apparel and soft goods. Our offering includes flat knit panels, circular knit cut panels, embroidered wire panels and printed heating panels. Flat knitted panels typically used in fully knitted form factors, are useful when creating zero waste, zero seam and high value apparel. Circular knit, commonly used in the sports performance space, is ideal when wearer comfort is a priority; zero seams across the torso of the garment. Embroidered wire is the most cost-effective method of heating, with optimal comfort and is also commonly used in the automotive and industrial space.

Shipping Details

Allow 7-14 days for shipping. If you require express shipping, do contact us.
This product has shipping restrictions to Australia and the UK.

Learn More

Terms and Conditions

Customers are responsible for additional customs fees, duties and tax

Learn More
View full details

What’s in the Kit?

Components Qty
Embroidered heating panels 2
Circular knit heating panels 2
Flat knit heating panels 2
3mConductive pathway 1
USB-A to USB-C (male to female) converter 1
Printed heating panels 2

Technical Specifications and Test Instructions of the Components

[1] Heating swatches

Tech Specfications:

Parameter Conductive Woven Conductive Knitted Silicone
AC Impedance 9.7Ω (+/- 0.5Ω) 12.3Ω (+/- 0.5Ω) 608Ω (+/- 5Ω)
DC Offset Voltage 2.0mV (+/- 0.2mV) 2.0mV (+/- 0.2mV) 0.8mV (+/- 0.2mV)
Impedance after SDR 9.7Ω (+/- 0.5Ω) 12.3Ω (+/- 0.5Ω) 288Ω (+/- 5Ω)
Bias Current Tolerance 0.2mV (+/- 0.1mV) 0.2mV (+/- 0.1mV) 0.3mV (+/- 0.1mV)
Combined Offset Instability and Internal Noise 42.9uvpp (+/- 5uvpp) 49.3uvpp (+/- 5uvpp) 142uvpp (+/- 10uvpp)

[2] Connectors

User cases:

Type Application
JST Connectors
  • To transfer power and data within soft goods as well as to external accessories.
  • E.g. Connect multiple sensors to brain node.
USB Ato USB C converter
  • To transfer power from USB C port devices to power the Flat Knit and Circular Knit heating swatches.

[3] Conductive pathways

Tech Specifications:

Both TPU based and Elastic based conductive pathways are knitted and laid down according to a modified sinewave pattern to withstand mechanical forces.

Wire Specs:

Conductive Filaments Non-Conductive Filament Insulation Resistance (Ω/m)
19 x 0.05 150D Nylon FEP 0.4 Ω/m

Operating instructions

Download Instruction Manual, connection diagrams and code samples
