Sensing Development Kit
Sensing Development Kit
Our fabric-based sensors are among the best when considering next-to-skin sensing. Our sensing suite spans IMU, ECG, EMG, pressure, and temperature sensing capabilities for all applications. The sensor types vary from knitted, woven, silicone and printed versions with varied specifications. Our toolkit also includes our popular interconnectors and data transmission cables for high-speed transfer of information. The sensors used can be treated no differently to traditional electronic sensors, and can be configured with most micro controllers. A functionality testing kit will also be included, to support the testing of all sensors included in the kit.
Couldn't load pickup availability
Shipping Details
Shipping Details
Allow 7-14 days for shipping. If you require express shipping, do contact us.
This product has shipping restrictions to Australia and the UK.
Terms and Conditions
Terms and Conditions
Customers are responsible for additional customs fees, duties and tax
Shipping Policy
PLEASE READ THESE TERMS OF USE CAREFULLY BEFORE USING THIS PLATFORM.
Softmatter is the smart wear technology arm of MAS Innovation (Private) Limited and this platform [Softmatter.io] is owned, controlled and managed by MAS Innovation (Private) Limited a subsidiary of MAS Holdings (Private) Limited (“TWINERY”).
By accessing or using this website or mobile application (collectively the “Platform”) on any computer, mobile phone, tablet, console or other device (collectively, “Device”), you signify that you have read, understand and agree to be bound by these Terms of Use and any other applicable law. . TWINERY may change these Terms of Use at any time without notice, effective upon its posting to the Platform. BY USING THE PLATFORM, YOU AGREE TO THESE TERMS OF USE; IF YOU DO NOT AGREE, DO NOT USE THE PLATFORM.
CONTENT
All intellectual property on the Platform is owned by TWINERY or its licensors, which includes materials protected by copyright, trademark, or patent laws. All trademarks, service marks and trade names (e.g., the TWINERY name) are owned, registered and/or licensed by TWINERY. All content on the Platform, including but not limited to text, software, scripts, code, designs, graphics, photos, sounds, music, videos, applications, interactive features and all other content (“Content”) is proprietary to TWINERY, protected by intellectual property laws including copyright and other proprietary rights of the United States and foreign countries. All rights reserved.
The Platform contains features that permit you to submit questions or comments (“User Content”). You retain the rights to your copyrighted User Content except as follows:
By submitting User Content to the Platform, you grant TWINERY a royalty-free, perpetual, irrevocable, non-exclusive, unrestricted, worldwide
Terms and Conditions
PLEASE READ THESE TERMS OF USE CAREFULLY BEFORE USING THIS PLATFORM.
Softmatter is the smart wear technology arm of MAS Innovation (Private) Limited and this platform [Softmatter.io] is owned, controlled and managed by MAS Innovation (Private) Limited a subsidiary of MAS Holdings (Private) Limited (“TWINERY”).
By accessing or using this website or mobile application (collectively the “Platform”) on any computer, mobile phone, tablet, console or other device (collectively, “Device”), you signify that you have read, understand and agree to be bound by these Terms of Use and any other applicable law. . TWINERY may change these Terms of Use at any time without notice, effective upon its posting to the Platform. BY USING THE PLATFORM, YOU AGREE TO THESE TERMS OF USE; IF YOU DO NOT AGREE, DO NOT USE THE PLATFORM.
CONTENT
All intellectual property on the Platform is owned by TWINERY or its licensors, which includes materials protected by copyright, trademark, or patent laws. All trademarks, service marks and trade names (e.g., the TWINERY name) are owned, registered and/or licensed by TWINERY. All content on the Platform, including but not limited to text, software, scripts, code, designs, graphics, photos, sounds, music, videos, applications, interactive features and all other content (“Content”) is proprietary to TWINERY, protected by intellectual property laws including copyright and other proprietary rights of the United States and foreign countries. All rights reserved.
The Platform contains features that permit you to submit questions or comments (“User Content”). You retain the rights to your copyrighted User Content except as follows:
By submitting User Content to the Platform, you grant TWINERY a royalty-free, perpetual, irrevocable, non-exclusive, unrestricted, worldwide
What’s in the Kit?
| Components | Qty |
|---|---|
| Knitted sensors | 2 |
| Woven sensors | 2 |
| Silicone sensors | 2 |
| Pressure sensor | 2 |
| Printed sensors | 2 |
| Respiration sensor | 1 |
| Mechanical connectors | 2 |
| Snap connectors | 2 |
| 3m Conductive pathway | 2 |
| High-speed data cables | 2 |
| Functionality kit | 1 |
Tech Specfications:
The ANSI EC12 Test Parameters for the Electrode types
| Parameter | Conductive Woven | Conductive Knitted | Silicone |
|---|---|---|---|
| AC Impedance | 9.7Ω (+/- 0.5Ω) | 12.3Ω (+/- 0.5Ω) | 608Ω (+/- 5Ω) |
| DC Offset Voltage | 2.0mV (+/- 0.2mV) | 2.0mV (+/- 0.2mV) | 0.8mV (+/- 0.2mV) |
| Impedance after SDR | 9.7Ω (+/- 0.5Ω) | 12.3Ω (+/- 0.5Ω) | 288Ω (+/- 5Ω) |
| Bias Current Tolerance | 0.2mV (+/- 0.1mV) | 0.2mV (+/- 0.1mV) | 0.3mV (+/- 0.1mV) |
| Combined Offset Instability and Internal Noise | 42.9uvpp (+/- 5uvpp) | 49.3uvpp (+/- 5uvpp) | 142uvpp (+/- 10uvpp) |
[2] Connectors
User cases:
| Type | Application |
|---|---|
|
Mechanical/Snap/ Magnetic Connector |
|
| JST Connectors |
|
[3] Conductive pathways
Tech Specifications:
Both TPU based and Elastic based conductive pathways are knitted and laid down according to a modified sinewave pattern to withstand mechanical forces.Wire Specs:
| Conductive Filaments | Non-Conductive Filament | Insulation | Resistance (Ω/m) |
|---|---|---|---|
| 19 x 0.05 | 150D Nylon | FEP | 0.4 Ω/m |
Operating instructions
Download Instruction Manual, connection diagrams and code samples
